Product features:
l The imported chip integrated circuit control system is adopted to ensure the high quality and high standard of the instrument
l 2.5-inch color LCD display; Display the set temperature and the actual temperature simultaneously; Countdown display of heat preservation time, and alarm when the time comes
l Automatic 6-stage temperature rise: The temperature and holding time of 6 consecutive stages can be set, and the instrument will automatically complete in order, which is simple and convenient to operate.
l Fully enclosed well-type electric heating is adopted, the sample is evenly heated, and the temperature is arbitrarily adjusted between room temperature and 200 deg C
l Advanced sensors are used to ensure that the set temperature remains unchanged, the use of solvents will not reach the ignition point, and improve the reliability and sensitivity of the system.
l Design of condenser tube without cock: leakage and glass tube damage caused by frequent rotation of cock are avoided; The sealing performance and the service life are effectively improved,
Automatic solvent recovery and storage
l Temperature limit protection: The upper limit of temperature can be set. When the actual temperature exceeds the upper limit, the instrument will automatically alarm and stop heating.
l Drying function: The sample can be dried directly on the instrument.
l The key parts of the fuselage are made of electrolytic mirror stainless steel, which is anti-corrosive, durable and beautiful.
Technology
Sample size | 0.5g to 15g (depending on sample type) |
Temperature control range | Room temperature ~ 200 ℃ (arbitrary adjustment) |
Detection range | 0.1-100% |
Solvent recovery method | Automatic recovery and storage |
Solvent recovery | ≥80% |
Reproducibility | RSD ± 1% (5-100% fat) |
Heating mode | Well-type electric heating |
Sealing method | Teflon seal |
Display mode | 2.5-inch LCD color screen; Display countdown of heat preservation time |
Capacity per batch | 6 samples |
Programmed temperature control | 6 stages can be set, and the program runs automatically |
Temperature control accuracy | ±0.2℃ |
Power | 500W |
Power source | 220（V）±10%，50~60HZ |
Overall dimensions | 560×370×685(mm) |
Weight | 32kg |
