Product features:
l The imported chip integrated circuit control system is adopted to ensure the high quality and high standard of the instrument
l 7-inch ultra-fine color screen, UI dynamic display, clear and simple interface, easy to operate
l The high suction filtration pump is made of corrosion-resistant solvent, which solves the problem of insufficient suction in the traditional way.
l There is no mechanical switch design in the machine body, and the corrosion-resistant and highly sensitive valve island group is adopted, so the operation is more efficient and smooth.
l Special semicircular silicon carbide heater, fast heating, stable temperature control, and durable
l Built-in back flushing pump solves the problem that the sample cake in the crucible can not be filtered
l The external reagent preheating barrel can heat the reagent in advance for preheating before the experiment, which speeds up the experiment time.
l The program has the function of preventing excessive liquid from overflowing, preventing corrosive liquid from overflowing due to wrong operation during liquid filling, and protecting the safety of operators.
l It can detect crude fiber, detergent fiber, hemicellulose, cellulose, lignin and other substances
Technical parameters:
Detection range |
0~100% |
Weigh the sampl |
0.5~3.0g |
Number of detections |
6 PCs/batch |
Temperature control accurac |
±0.1℃ |
Heating mode |
Semicircular silicon carbide heater |
Repeatability | The crude fiber content is below 10%, ≤ 0.4 |
The crude fiber content is above 10%, ≤ 1% |
Display mode | 7-inch touch color screen |
Liquid adding mode |
Program-controlled, automatic injection |
Control mode |
UI dynamic interface, automatic one-click |
Power source |
220（V）±10%, 50~60HZ |
Power | 1500W (host) |
1200 W (anti-dry liquid boiler) |
Overall dimensions |
620*440*655mm |
Weight | 45kg |
